Adhesive cartridge with static mixer ~ applicator gun sold separately

Description

W4S 2-part Methacrylate Adhesive (400ml 1:1 Mix)

Wired4Signs USA has worked together with a leading USA adhesives manufacturer to develop a 2-part Plastic Epoxy methacrylate adhesive to bond most substrates such as steel, aluminum, Plexiglass (Acrylics) and Polycarbonate, PET, ABS, and other plastics. This glue is commonly known as 2-part plastic epoxy but actually a methacrylate (MMA) is widely used for display, signage, electronics, marine, fiberglass and other industrial bonding applications.

See the advantages on the following blog and also, see our blog on structural bonding vs mechanical fastening. We also have an instructive overview of the two-part adhesive cartridge and static mixer systems.

W4S55300 adhesives are not UV stable, and will yellow over time and must not be used to create imperceptible seams in countertops or for seaming countertops. This yellowing will not affect bond performance, but will affect bond appearance.

The shelf life of W4S55300 is twelve (12) months from the date of manufacture based upon continuous storage at room temperature (77°F or 25°C). Storage of W4S55300 adhesives in refrigerated compartments will extend the shelf life even more. Do not store W4S55300 adhesive or any other adhesives in a refrigerator which has food in it. Be sure to bring W4S55300 adhesives to room temperature for 24 hours before use, otherwise longer cure and fixture times may be expected. Long-term storage at temperatures above room temperature will shorten the shelf life of W4S55300 adhesives considerably. Storage at temperatures above 100°F or 38°C could shorten the shelf life to less than one month. W4S55300 adhesives contain no water, so freezing of the adhesive for short periods is permissible, but is not encouraged.

Key features

• General-purpose workhorse
• Good gap filling

General specifications

• Color: Cream
• Package size: 400 ml
• Mix ratio: 1:1
• Mixer system: C-System
• Suitable materials:
  • Steel & stainless steel
  • Aluminum
  • Fiberglass
  • Various plastics, including ABS, PVC, PET, acrylics, and polycarbonate (not low-surface-energy plastics)

• Working time: 3–6 minutes (@ 24°C)
• Handling strength: 18–24 minutes (@ 24°C)

• Gap fill: 1/4" (6.35 mm)
• Shelf life: 12 months
• UV stable: No
• Viscosity (Brookfield T Bar): 70,000 – 120,000 cP (Like creamy peanut butter)
  • Resin: 40,000 – 90,000 cP
  • Activator: 100,000 – 150,000 cP
• Tensile strength (ASTM D638):
  • Fiberglass surfaces: 17+ MPa / 1000+ psi (substrate failure)
  • ABS/PVS sheeting: 7+ MPa / 1000+ psi (substrate failure)
  • Steel/Stainless steel: 17–24 MPa / 2500–3500 psi
  • Aluminum: 17–24 MPa / 2500–3500 psi
• Lap shear strength (ASTM D1002): Unknown
• Chemical resistance:
  • Resistant to:
    • Hydrocarbons
    • Acids and bases
    • Vinegar
    • Wine and condiments
    • Most household foods
  • Susceptible to:
    • Polar solvents
    • Super-strong acids and bases

Downloads

• W4S 55300 spec sheet
• Part A MSDS
• Part B MSDS

Important information

• This product is manufactured in the USA and we ship stock out of Knoxville, TN, USA.
• Excellent and cost effective comparison to ASI MP55300 2-part adhesive.
• Please contact us directly for bulk pricing or custom labeling options.
• This cartridge is supplied with one static mixer nozzle. Additional mixers nozzles are available from the accessories below.
• This cartridge requires a reusable dispensing gun. Please order from the accessories below.

• The static mixers are disposable and last the set time of the glue. So as long as you keep the product moving the nozzles will work.
• This adhesive is available in two different colors - Cream (Straw) and Black (Negra)

We have a wide range of product formulation and cartridge type to virtually match any of our competitors products. Contact us to correctly cross reference the product.
